Product Summary
The Yamaha DBR12 is a versatile 12" 2-way powered loudspeaker, delivering up to 1000W of dynamic output with a Class D amplifier. It features a 12" woofer and a 1.4" high-frequency driver, achieving a maximum output of 131 dB. The speaker includes a 2-channel mixer with XLR, TRS, and RCA inputs, suitable for various audio sources. Its lightweight design and ergonomic handle ensure easy portability.
Key Features
- 1000W Class D amplifier with 12" woofer and 1.4" HF driver
- Maximum output of 131 dB SPL
- 2-channel mixer with XLR, TRS, and RCA inputs
- FIR-X tuning for high-resolution sound quality
- D-Contour optimization for main or monitor use
Still Unsure? Ask Our Experts
Our trained Studio Sales Engineers are here to help
Product Gallery
Additional Product Information
Product Details
Giving you the flexibility of using it for floor monitoring, front of house, or rigged applications, the DBR12- 12" 2-Way Powered Loudspeaker from Yamaha is capable of up to 1000W of dynamic output via its Class D amplifier. The loudspeaker features a 12" woofer and a 1.4" high-frequency driver and provides a maximum output of 131 dB. An on-board 2-channel mixers allows you to connect microphone or line level sources via 1/4", XLR, and RCA connectors. Thanks to its ergonomic handle and lightweight design the DBR12 is portable and can be easily transported.
DBR Series speakers have two input channels. Channel 1 has a combo jack which accepts both XLR and TRS Phone allowing for either Mic or Line level input signals. Channel 2 offers two input options; a combo jack that accepts XLR or TRS Phone, and a stereo RCA pin jack for input from CD players or other stereo line-level sources. The onboard mixer allows you to select either Channel 1 + 2 MIX to mix the signal of Channel 1 and Channel 2, or Channel 1 THRU to pass the signal from Channel 1 only
Highlights
- FIR-X tuning delivers excellent sound quality with high resolution and a smooth frequency response
- D-Contour optimizes the DBR12 for main speaker or floor monitor use
- Onboard mixer lets you select either a direct output or a mixed output
- Comprehensive inputs for mixer, musical instrument, or media players
- Amplifier and power supply design provides powerful output from a compact speaker
- DSP-controlled protection functionality promotes optimum reliability
Technical Specifications
- Powered; Yes
- Power Configuration; Bi-amped
- LF Driver Size: 12"
- HF Driver Size: 1.4"
- LF Driver Power Amp: 800W
- HF Driver Power Amp 200W
- Total Power: 1000W
- Frequency Range: 52Hz-20kHz (-10 dB)
- Crossover Frequency: 2.1kHz
- Maximum Peak SPL: 131dB
- Horizontal Coverage Angle: 90 Degrees
- Vertical Coverage Angle: 60 Degrees
- Enclosure Material: Plastic
- Mounting Options: Pole, Floor Wedge
- Inputs: 2 x XLR/TRS Combo, 1 x stereo RCA
- Outputs: 1 x XLR
- Height: 23.7"
- Width: 14.8"
- Depth: 13.7"
- Weight: 34.8 lbs.
Tech Specs
- SKU:
- CDBR12UK
- Model Name:
- DBR12
- Brand:
- Yamaha
Size & Weight
- Height:
- 60.20 (cm)
- Width:
- 37.60 (cm)
- Depth:
- 34.80 (cm)
- Weight:
- 15.80 KGS
