Top Performance & Distortion Free Audio
The MAUI 28 G2 consists of two 6.5" woofers, sixteen 3" full range transducers and dual 1" neodymium compression drivers that work together to producer punchy low ends, a balanced mid-range and smooth highs. This combination is driven by a lightweight class D amplifier with a powerful peak power of 2000w. The LD Systems' DSP technology includes a multiband limiter, EQ, a compressor and a 3-way crossover to ensure the PA system continually delivers a top tier sound performance.
Line Array Configuration
Extended coverage, high feedback resistant and extra wide dispersion without the need for separate monitors is featured in this PA system thank to the MAUI 28 G2's line array configuration. Using BEM (the numerical modeling of sound radiation and propagation) the high frequency drivers' waveguide reduces floor and ceiling reflections which ultimately eliminates side lobes and ensures the audience can hear you from the front to the back.
Total Control
The MAUI 28 G2 column PA system gives you total control with a built-in 4-channel mixer, mono and stereo setup presets and Bluetooth audio streaming. Whether you're a singer-songwriter, solo entertainer or DJ you can appreciate the powerful audio performance with the convenience of portability. The column and sub can be separate, making the PA system very flexible and a suitable choice for installed sound applications.
Highlights
- Suitable for medium sized gigs and installations
- Consists of 2 x 8" woofers, 16 x 3" fullrange transducers & dual 1" neodymium compression drivers
- Lightweight class D amplifier with huge 2000w peak power
- LD systems' Dynx DSP technology ensures top performance and distortion-free audio
- Includes multiband limiter to prevent clipping
- Extended coverage, high feedback resistance and extra wide dispersion
- Column and sub can be separated
Technical Specifications
General
- Product Type: PA Complete Systems
- Type: Active
- Colour: Black
- Max SPL (Peak): 126dB
- Frequency Response: 45 - 20000Hz
- Dispersion (H x V): 120 x 20
- Overall Height: 2059 mm
- Weight: 31.2 kg
Woofer Characteristics
- Low/Mid Driver Dimensions: 2 x 8" (2 x 203 mm)
- Woofer Magnet: Ferrite
- Woofer Brand: Custom Made
- Woofer Voice Coil: 2" (50.8 mm)
- Cabinet Construction: Vented
- Cabinet Material: 15 mm Plywood
- Cabinet Surface: Texture Paint
- Subwoofer Width: 370 mm
- Subwoofer Height: 484 mm
- Subwoofer Depth: 480 mm
- Subwoofer Weight: 20.2 kg
Mid/Hi system
- Midrange Size: 16 x 3" ( 16 x 76.2 mm)
- Midrange Magnet: Ferrite
- Midrange Brand: Custom Made
- Midrange Voice Coil: 1" (25.4 mm)
- Horn: Waveguide
- Tweeter Dimensions: 2 x 1" (25.44 mm)
- Tweeter Magnet: Neodymium
- Tweeter Brand: Custom Made
- Tweeter Voice Coil: 1" (25.4 mm)
- Loudspeaker Inputs: 1
- Speaker Input Connections: Custom Made Multipin
- Cabinet Construction Mid/High: Closed
- Mid/Hi System Cabinet Material: Aluminium
- Mid/Hi System Cabinet Surface: HD Coating
- Mid/Hi System Width: 96 mm
- Mid/Hi System Height: 780 / 795 mm
- Mid/Hi System Depth: 104 mm
- Mid/Hi System Weight: 5.6 / 5.4 kg
Amplifier Module (Integrated In Subwoofer)
- Amplifier: Class D
- Amplifier Output System (RMS): 1000w
- Amplifier Output System (Peak): 2000w
- Protection Circuits: Thermal Overload, Short Circuit, DC Protection, Multiband Limiter
- Cooling: Convection
- Operating Temperature: 0 - 40C
- Humidity Range: 0% - 80% Rel. (Non Condensing)C
- Controls: MP3/Bluetooth Level, Bluetooth Button, Line Level, Mono/Stereo Switch, Main Level, Sub level, Power, Hi-Z Level
- Indicators: Signal, On, Limit, Setup, Mono, Stereo, Protect (Protection Circuit Engaged)
- Power Connector: IEC (Power Cable Included)
- Operating Voltage: 100 - 120V / 50 - 60Hz Oder 200 - 240 V / 50 - 60Hz (Automatic Conversion)
- Power Consumption: Off: 0w, On: 11w, Max: 600w
- Line Inputs: 2 x Stereo
- Line Input Connectors: XLR/6.3 mm Jack, RCA
- Line Outputs: 1 x System Out, 1 x Sub Out
- Line Output Connectors: XLR
- Mic Inputs: 1 x XLR/6.3 mm Jack
- MP3 Inputs: 1
- MP3 Input Connectors: 3.5 mm Jack
- Hi-Z Input: 1
- Hi-Z Input Connectors: 6.3 mm jack
- Loudspeaker Outputs: 1
- Speaker Output Connections: Custom Made Multipin
DSP Characteristics
- Bit Depth AD/DA Converter: 24bit
- Internal Sampling Frequency: 48kHz
- Signal/Noise Ratio: 100dB
