JBL LSR708i (Single)

The first in JBL’s new 7 Series line, the 705i and 708i models answer the call for next generation multi-channel monitoring in post rooms, broadcast facilities and trucks. Leveraging patented technologies developed for our flagship M2 Master Reference Monitor, 7 Series Studio Monitors deliver detailed imaging, extended frequency response and remarkable output from compact enclosures. Centrally amplified and tuned, and easily installed, 705i and 708i Studio Monitors are the heart of an elegant, scalable system for broadcast and post facilities working in immersive audio formats.

Highlights

• Next Generation Systems for Post and Broadcast Production in Control Rooms and Trucks
• Next Generation Driver Technology
• Patent Pending Image Control Waveguide
• Compact, Install Friendly Enclosures
• Modular and scalable for number of channels and room size
• 7 Series Studio Monitors and the JBL M2 Master Reference Monitor can be combined to produce a wide range of systems
• Compact enclosures and mounting hardware allow versatile mounting options and unobstructed sight lines
• Centralized amplification and processing eliminates the requirement for power source at each speaker location
• BSS BLU link Networked Audio for ease interface and reduced system noise
• Harman HiQnet equipped components can be centrally controlled via hardware, software or wireless tablet

Technical Specifications

• Frequency Response -1.5 dB @ 45Hz – 23kHz
• Frequency Range -  35Hz – 36 kHz
• Max SPL - (80 Hz - 20 kHz) >108 dB SPL / 1m
• Maximum Peak SPL -  (80 Hz - 20 kHz) >114 dB SPL / 1m
• HF Driver - 2409H
• LF Driver - 728G
• Dividing - Network
• Transition Frequency - 1.7 kHz
• Input Types - Phoenix Terminals accept 12 gauge speaker wire
• Dimensions - (HxWxD) 17.25 x 9.75 x 11.5 in (438 x 248 x 292 mm)
• Weight Each - 25.2 lb (11.5 kg)
• Enclosure - Birch plywood reinforced for mounting
• Mounting - Top, bottom and rear mounting points. 4-hole mounting pattern
