Genelec 8330A - Dark Grey (Single) 2-Way DSP Active Studio Monitor

The 8330A features Genelec MDE™ and DCW™ technologies, a flow optimized reflex port, high SPL and wide uncoloured response in a very compact enclosure. A new and highly intuitive Genelec Loudspeaker Manager (GLM™ 2.0) control network and software allows adjustments of all aspects of monitor settings and full system control. Genelec AutoCal™ allows to automatically align every monitor on the network for level, timing, and equalisation of room response anomalies.

An indispensable tool in challenging room acoustic, the 8330A is the monitoring solution for music studios, post-production houses, digital edit suites, radio, TV and outside broadcasting.

Highlights

• Smart Active Monitor (SAM™) Systems
• Directivity Control Waveguide (DCW™) Technology
• Minimum Diffraction Enclosure (MDE™) Technology
• Reflex Port Design
• Optimized Amplifiers
• Active Crossovers
• Protection Circuitry
• Intelligent Signal Sensing (ISS™) Technology
• Iso-Pod™ Stand
• Versatile Mountings

Technical Specifications

• SPL - 104 dB
• Frequency response - 45 Hz – 23 kHz (-6 dB)
• Accuracy of frequency response - ± 1.5 dB (58 Hz - 20 kHz)
• Driver dimension - Woofer 5 inch + Tweeter 3/4 inch metal dome + DCW™
• Amplifier power - Woofer 50 W + Tweeter 50 W (All Class D)

• H 299 x W 189 x D 178 mm, 11 7/8 x 7 1/2 x 7 1/16 inch, with Iso-Pod™
• Weight - 5.5 kg / 12.1 lb

• 1 x XLR analog input, 1 x input / 1 x output XLR digital AES/EBU, 2 x RJ45 control network
