2-Way DSP Active Studio Monitor

  • Genelec 8330a (Single) Studio Monitor Angle
  • Genelec 8330a (Single) Studio Monitor Back
£638.88 Inc VAT
Checking Availability...
Add Items to Basket
Pay4Later
Own this for as little as...
£
per month
x payments +
£ deposit
Apply for credit at checkout



Quick Overview

Genelec 8330a (Single) is a 2-Way DSP Active Studio Monitor that features Genelec MDE™ and DCW™ technologies

  • Description
  • Additional Information
  • Alternative Products

Genelec 8330a (Single) Packages

Genelec 8330a (Single) Product Description

The 8330A features Genelec MDE™ and DCW™ technologies, a flow optimized reflex port, high SPL and wide uncoloured response in a very compact enclosure. A new and highly intuitive Genelec Loudspeaker Manager (GLM™ 2.0) control network and software allows adjustments of all aspects of monitor settings and full system control. Genelec AutoCal™ allows to automatically align every monitor on the network for level, timing, and equalisation of room response anomalies.

An indispensable tool in challenging room acoustic, the 8330A is the monitoring solution for music studios, post-production houses, digital edit suites, radio, TV and outside broadcasting.

Highlights

  • Smart Active Monitor (SAM™) Systems
  • Directivity Control Waveguide (DCW™) Technology
  • Minimum Diffraction Enclosure (MDE™) Technology
  • Reflex Port Design
  • Optimized Amplifiers
  • Active Crossovers
  • Protection Circuitry
  • Intelligent Signal Sensing (ISS™) Technology
  • Iso-Pod™ Stand
  • Versatile Mountings

Technical Specifications

  • SPL - 104 dB
  • Frequency response - 45 Hz – 23 kHz (-6 dB)
  • Accuracy of frequency response - ± 1.5 dB (58 Hz - 20 kHz)
  • Driver dimension - Woofer 5 inch + Tweeter 3/4 inch metal dome + DCW™
  • Amplifier power - Woofer 50 W + Tweeter 50 W (All Class D)
Dimensions
  • H 299 x W 189 x D 178 mm, 11 7/8 x 7 1/2 x 7 1/16 inch, with Iso-Pod™
  • Weight - 5.5 kg / 12.1 lb
Connections
  • 1 x XLR analog input, 1 x input / 1 x output XLR digital AES/EBU, 2 x RJ45 control network

Genelec 8330a (Single) Additional Information

SKU 8330APM
Brand Genelec
Condition New
Sold As Single
Speaker Type Active
Speaker Configuration 2-Way
LF Driver Size 5"
LF Amplifier 50W
HF Driver Size 0.75"
HF Amplifier 50W
HF Driver Material Dome
Total Power 100W
Min Frequency Response (Hz) 45 Hz
Max Frequency Response (kHz) 23 kHz
Max SPL 104 dB
Port Configuration Rear Ported
Input Connectivity XLR, XLR Digital AES/EBU
Output Connectivity XLR Digital AES/EBU
EAN 06438128100458
