The R20 records directly to SDHC or SDXC cards up to 1TB. The colour coded faders, gain knobs and track regions on the 4.3-inch colour touchscreen ensure an unparalleled simple workflow. The R20 is the first multi-track recorder that allows accessibility for the visually impaired as the R20 app features VoiceOver and VoiceOver Gestures.
Furthermore, the R20 offers 150 internal rhythm patterns and supports Standard MIDI files to import and play back bass lines, melodies, piano parts, etc. to create backing tracks with an ease.
In addition, the R20 features an internal synthesizer with 18 sounds +1 drum kit, playable via a MIDI keyboard connected via USB-C. To spice things up, an EQ, compressor, and gate as well as a full MFX processor, which is compatible with our Guitar Lab software, are at your fingertips. The R20 works also as an 8-in/4-out USB-C audio interface with a Mac or PC. The R20 makes it insanely simple to track, edit and mix your songs, letting you focus on the music.
Highlights
- 4.3” Full-color LCD touchscreen display
- Easy-to-use DAW-inspired interface
- Record up to 16 tracks (8 simultaneously)
- Eight XLR mic preamps, including two mic/line/instrument combo jacks
- Hi-Z available on input 1 and 48V phantom power available on inputs 5-8
- Color-coded volume faders, gain knobs and tracks
- Onboard editing and built-in effects
- Built-in MFX processor compatible with Guitar Lab Software
- 150 pre-loadeded drum loops
- Internal synthesizer with 18 sounds + 1 drum kit, playable over MIDI Keyboard connected to USB-C
- Load and playback standard MIDI files
- Optional BTA-1 Bluetooth enables wireless control via the R20 Control App
- USB-C audio interface up to 8-in / 4-out
- Records directly to SDHC cards up to 32GB and SDXC cards up to 1TB
- New locking-type AC adapter (ZAD-1220)
- Up to 24-bit /44.1kHz audio in BWF-compliant WAV
- Compatible with Guitar Lab software for Mac/Windows PC
Technical Specifications
- INPUTS / OUTPUTS
- • Inputs
- • MIC/LINE (mono)
- • 8
- • Outputs
- • MASTER OUT
- • 1
- • PHONES
- • 1
- • INPUTS
- • MIC/LINE (mono)
- • Connectors
- • XLR/TRS combo jacks × 2
- • XLR × 6
- • (XLR: 2 HOT/TRS: TIP HOT）
- • Input gain
- • −3 – +40 dB
- • Input impedance
- • XLR: 3.9 kΩ
- • TRS: 5.3 kΩ/1 MΩ (when Hi-Z is ON, for INPUT 1 only)
- • Maximum input level
- • +4 dBu (@0 dBFS)
- • Phantom power
- • +48 V (INPUTS 5–8, switchable in pairs)
- • Equivalent input noise
- • –121 dBu or less (IHF-A) with +40dB/150Ω input
- • Frequency response
- • –1.0 dB: 20 Hz – 20 kHz
- • OUTPUTS
- • MASTER OUT
- • Connectors
- • 2 TRS phone jacks (balanced)
- • Maximum output level
- • +14 dBu
- • Output impedance
- • 200 Ω
- • PHONES
- • Connector
- • 1 standard stereo phone jack
- • Maximum output level
- • 20 mW + 20 mW (into 32Ω load)
- • Output impedance
- • 33 Ω
- • TRACK SETTINGS
- • Pan
- • EQ
- • High: 10 kHz, ±12 dB, shelving
- • Middle: 2.5 kHz, ±12 dB, peaking
- • Low: 100 Hz, ±12 dB, shelving
- • Send Effect
- • Stereo Link
- • Comp/Limiter/Gate
- • RECORDER
- • Maximum simultaneous recording tracks
- • 8
- • Maximum simultaneous playback tracks
- • 16
- • Recording format
- • 44.1kHz, 16/24-bit, mono/stereo WAV
- • Recording media
- PRESS RELEASE OF SOUND SERVICE GMBH, Moriz-Seller Str. 3, 12489 Berlin,
- E-Mail: info@sound-service.eu, Website: www.sound-service.eu
- Fon +49 (0) 30 707 130-0, Fax: +49 (0) 30 707 130-189
- PRESS RELEASE
- • 4–32GB cards compatible with the SDHC specification 64–1TB cards compatible with the SDXC
- specification
- • EFFECTS
- • Maximum number of simultaneous effects
- • 3 effects
- • One insert effect on one channel or one send effect available to all tracks
- • Patch memories
- • 50
- • Guitar Lab compatible
- • TUNER
- • Chromatic/Guitar/Bass/Open A/Open D/Open E/Open G/DADGAD
- • METRONOME
- • Time signatures
- • 3/4, 4/4, 6/8
- • Tempo range
- • 40.0–250.0 BPM
- • RHYTHM LOOPS
- • Sound source format
- • PCM
- • Number of loops
- • 150 or more
- • SYNTH
- • Polyphony
- • 8
- • Sound source format
- • FM
- • Number of sound types
- • 18 (including PCM drum kit)
- • DISPLAY
- • 4.3" (480×272) full-color touchscreen LCD
- • USB
- • Connector
- • USB-Type-C
- • Use a USB cable that supports data transfer.
- • USB bus power is not supported.
- • Audio interface operation
- • Stereo mix
- • USB 2.0 Full Speed
- • 44.1kHz, 24-bit
- • 2-in/2-out
- • Multitrack
- • USB 2.0 High Speed
- • 44.1 kHz, 16/24-bit
- • 8-in/4-out
- • Mass storage operation
- • Host/Device
- • USB 2.0 High Speed (5V/500mA power supplied when host)
- • Guitar Lab connection
- • USB 1.1 Full Speed
- • USB-MIDI keyboard connection
- • USB 1.1 Full Speed (5V/500mA power supplied)
- • DAW connection (control surface) function
- • USB 1.1 Full Speed
- • REMOTE
- • Dedicated wireless adapter (ZOOM BTA-1)
- • POWER
- • AC adapter (ZOOM ZAD-1220): 12 V/2.0 A
- • Power consumption
- • 11 W maximum
- • External dimensions
- • 378 mm (W) × 206 mm (D) × 58 mm (H)
- • Weight (unit only)
- • 1.33 kg
